Garaga G-8500 Industrial Door
Features
- 24-gauge, hot dipped-galvanized steel.
- 2 in. (50 mm) insulated door with 1 7/16po (36.5 mm) CFC-free Polystyrene protected with a rigid styrene sheet.
- R-Value 6.6 (RSI:1.2).
- Finely embossed woodgrain design Deep ribbed steel for extra sturdiness.
- Flexible EPDM bottom weatherstripping.
- 20-gauge galvanized steel attached by a Tog-L-Loc® joining system with no rivets at hinge placement locations.
Price comparison*
* For a door of the same dimensions and with the same hardware system. Installation included. Manual operation. Price comparison may vary depending on the cost of the door opener and accessories.Door model
Price difference compared to the G-5000
G-1000 (aluminum of 0,60 mm) R-16 (k=0,357 W/m 2 K) 120 G-2323 (23 gauge steel) R-16 (k=0,357 W/m 2 K) 133 G-2023 (20/23 gauge steel) R-16 (k=0,357 W/m 2 K) 146 G-2020 (20/20 gauge steel) R-16 (k=0,357 W/m 2 K) 176 G-4400 (station service door) R: not applicable Because this door is fully glazed, it is difficult to compare with others. G-5000 (26 gauge steel) R-16 (k=0,357 W/m 2 K) 100 G-5138 (26 gauge steel) R-12 (k=0,476 W/m 2 K) 95 G-8000 (24 gauge steel) Non-insulated 55 G-8500 (24 gauge steel) R-6.6 (k=0,860 W/m 2 K) 75 Colours
The G-8500 is offered in Ice White only with a corrosion resistant, baked-on polyester base paint. Note this door can be repainted.
Ice WhiteWarning
Note that the accuracy of colours on the website may vary depending on your screen settings. To see the true colours, please contact your local Garaga dealer for a sample.Woodgrain finish
Grooved Patterns
Windows
Single clear plain glass window 1/8 inch (3 mm) is inserted into an expanded PVC frame which is cast without joints. Size: 21 X 13 in. (533 X 330 mm).Hardware System
- 13-gauge or 14-gauge, 2 in. (51 mm) commercial tracks (for doors of less than 140 ft2 (13 m2) or 12-gauge 3 in. (76 mm) industrial tracks.
- Torsion spring
Available Sizes
Widths: from 6 ft. to 24 ft., in 1-inch increments (from 1.8 m to 7.3 m, in 25 mm increments) Heights: from 8 ft. to 18 ft., in 3-in. increments. Note: 8’3”, 8’6” and 10’3” are not available (fom 2.4 m to 5.5 m, in 76 mm increments)Features
Features
- 24-gauge, hot dipped-galvanized steel.
- 2 in. (50 mm) insulated door with 1 7/16po (36.5 mm) CFC-free Polystyrene protected with a rigid styrene sheet.
- R-Value 6.6 (RSI:1.2).
- Finely embossed woodgrain design Deep ribbed steel for extra sturdiness.
- Flexible EPDM bottom weatherstripping.
- 20-gauge galvanized steel attached by a Tog-L-Loc® joining system with no rivets at hinge placement locations.
Price comparison*
* For a door of the same dimensions and with the same hardware system. Installation included. Manual operation. Price comparison may vary depending on the cost of the door opener and accessories.Door model
Price difference compared to the G-5000
G-1000 (aluminum of 0,60 mm) R-16 (k=0,357 W/m 2 K) 120 G-2323 (23 gauge steel) R-16 (k=0,357 W/m 2 K) 133 G-2023 (20/23 gauge steel) R-16 (k=0,357 W/m 2 K) 146 G-2020 (20/20 gauge steel) R-16 (k=0,357 W/m 2 K) 176 G-4400 (station service door) R: not applicable Because this door is fully glazed, it is difficult to compare with others. G-5000 (26 gauge steel) R-16 (k=0,357 W/m 2 K) 100 G-5138 (26 gauge steel) R-12 (k=0,476 W/m 2 K) 95 G-8000 (24 gauge steel) Non-insulated 55 G-8500 (24 gauge steel) R-6.6 (k=0,860 W/m 2 K) 75 Colours and Designs
Colours
The G-8500 is offered in Ice White only with a corrosion resistant, baked-on polyester base paint. Note this door can be repainted. Ice WhiteWarning
Note that the accuracy of colours on the website may vary depending on your screen settings. To see the true colours, please contact your local Garaga dealer for a sample.Woodgrain finish
Grooved Patterns
Windows
Windows
Single clear plain glass window 1/8 inch (3 mm) is inserted into an expanded PVC frame which is cast without joints. Size: 21 X 13 in. (533 X 330 mm).Hardware
Hardware System
- 13-gauge or 14-gauge, 2 in. (51 mm) commercial tracks (for doors of less than 140 ft2 (13 m2) or 12-gauge 3 in. (76 mm) industrial tracks.
- Torsion spring
Specifications
Available Sizes
Widths: from 6 ft. to 24 ft., in 1-inch increments (from 1.8 m to 7.3 m, in 25 mm increments) Heights: from 8 ft. to 18 ft., in 3-in. increments. Note: 8’3”, 8’6” and 10’3” are not available (fom 2.4 m to 5.5 m, in 76 mm increments)
